USB-C® Tx & Long Chnnel Rx Precet. Test Fixture

治具编号:AUT20044 Rev:B0

产品介绍

Intel USB-C 3.1 Tx 测试,需要使用两个不同的治具,个别for UFP和DFP。最令人伤脑筋的是,用几个月就坏了,无法维修。百佳泰 Pre-cert 治具,整合两片的功能,只要简单的切换,不用一直交换治具。

应用范围

USB-C 3.1 Tx Signals Integrity Test

主要特性

  • Combine UFP/DFP testing in one Fixture
  • Better Signals quality than orignal Test Fixture

产品规格

  • One USB-C Receptacle
  • One USB-C Plug for DUT connection
  • Four SMA connectors for SSTX1/SSTX2
  • Two Slide Switchs for CC1/CC2 & RP/RD Setting
  • One USB-C for External +5V Power in UFP Testing
